Stacked official word:
TBA
Chase Bicycles word:
The CHASE Edge is a pure BMX racing machine, ideal for improving and taking it to the next level after starting the BMX Race. Now equipped with a disc braking system and closed rear dropout system, it has a hydroformed triple butted 6061 aluminum frame with integrated headset, a chromoly fork and handlebars, a crankset with INSIGHT chainring, double wall rims with cassette rear hub and TIOGA Powerblock tires. The combination of all these components arguably makes the CHASE Edge one of the most advanced race BMX bikes on the market today.
Recommend rider height 4’4” - 4’10”
SPECS
Geometry-
Toptube: 19.75”
Seattube: 72°
Chainstay: 13”
Standover: 8.8”
Headtube: 73°
BB Height: tba
Specs-
Frame: CHASE Edge Expert 19.75" Top Tube, 6061 T6 Alloy Triple Butted Hydroformed, Integrated Head Tube, Enclosed Rear Dropouts And Chain Tensioner System
Forks: CHASE Edge Full Cr-Mo, 1-1/8" Steer Tube, Tapered Blades
Handlebars: Chase Edge Cr-Mo 5.75" Rise, 25.5" Wide, 8° Back Sweep & 2° Up Sweep
Grips: INSIGHT C.O.G.S 130mm Lock-On
Barends: PVC end plugs
Stem: Chase Edge CNC’d alloy with laser etched logo, top load, 50mm reach
Headset: Integrated IS 42/42 1-1/8", Sealed Bearing
Brake Lever: Tektro alloy
Brake Cable: Stainless steel
Brakes: Mechanical, 140mm Disc Rotor, Shimano B01S Compatible Pads, Lock Disc Adaptor
Cranks: CHASE Edge 3 Piece Crank 165mm Alloy Arm, Cr-Mo Chainring Bolts
Bottom Bracket: 118mm Euro, ISIS, Sealed Cartridge
Pedals: Pro Platform 9/16" Barrel Polished With Grip Nodes, Axle Boron Steel, Ball Bearing
Chain: KMC Z1 Narrow 1/2"X3/32"
Sprocket: Insight 42 Tooth 5 Bolt 110mm 1/2"X3/32" 3mm Alloy Ring
Front Hub: Mini 28H, Sealed Bearing, 10mm Axle, M6 Bolts
Rear Hub: Mini ISO 28H, Sealed Bearing, 10mm Axle, M6 Bolts, Steel Cassette Body With 3 Pawls At Triple Angle Engagement For 24T Ratchets
Driver: 16 Tooth
Front Rim: Chase Edge Alloy 138 Double Wall 28H 20"X1-3/8" Schrader Valve
Rear Rim: Chase Edge Alloy 138 Double Wall 28H 20"X1-3/8" Schrader Valve
Seat: Pro pivotal
Seat Post: pivotal 25.4mm, alloy
Seat Clamp: Chase Edge 26.8mm quick-release
Rear Tire: 20x1 3/8” Tioga Power Blocks high pressure
Front Tire: 20x1 3/8” Tioga Power Blocks high pressure
Chain tensioner: Insight twin hole laser etched alloy
Pegs: N/A
Gyro Tabs: no
Weight: 18.67 lbs
